* SPECIFICATION * Standard Model GS - 2000A GS - 3000A GS - 5000A Fluid N2,C3H8, NH3, CO2, C4H10, Freon , etc No. of Cylinder 1 2 3 Inlet Pressure Min, 2.22 Mpa Discharge Pressure Max, 1.93 Mpa Piston 400 RPM 6.8 NM3/h 13.6 NM3/h 28.9 NM3/h Displcement 825 RPM 14.1 NM3/h 27.2 NM3/h 61.2 NM3/h CompressionRation Continn. 5 Intermit. 7 Motor 2.2 Kw 5.5 Kw 11 Kw * APPLICATION - Gas Transfer - Cylinder Fillingl
* SPECIFICATION
* Standard
Model
GS - 2000A
GS - 3000A
GS - 5000A
Fluid
N2,C3H8, NH3, CO2, C4H10, Freon , etc
No. of Cylinder
1
Inlet Pressure
Min, 2.22 Mpa
Discharge Pressure
Max, 1.93 Mpa
Piston
400 RPM
6.8 NM3/h
13.6 NM3/h
28.9 NM3/h
Displcement
825 RPM
14.1 NM3/h
27.2 NM3/h
61.2 NM3/h
CompressionRation
Continn.
Intermit.
Motor
2.2 Kw
5.5 Kw
11 Kw
* APPLICATION
- Gas Transfer - Cylinder Fillingl
