* SPECIFICATION

* Standard

Model

GS - HV - 250A

GS - HV - 250B

Material

F304 / C3771B

Fluid

O2 / N2/ Ar/ CO2/ H2  etc

Working Pressure

25 Mpa

Design Temperature

- 10 ~ 80 ℃

End Connection

B/W / S/W / Flare Screw

Seat Diameter

10 MM

14 MM

Size

1/2 B

3/4 B
